GPS Trainer





The GPS Trainer Model 7524 is a 12 channel continuous tracking GPS receiver optimized for high sensitivity and low cost applications. The GPS signal is applied to the antenna input of the module, and a complete serial data message with position, velocity and time information is presented at the serial interface.

The GPS10 contains a low noise amplifier for passive antenna operation, RF down converter, baseband processor, flash memory and navigation software. The module provides excellent navigation performance under static or dynamic conditions in areas with limited sky view like urban canyons, fast TTFF for weak signaloperation. Power saving mode make this product suitable forhandheld and battery-operated devices.

     FEATURES

†               Channels                                         :                 12

†               Frequency                                      :                 1575.42 MHz – L1 C/A

†       Position Accuracy                           :                 25 meters CEP without SA or higher

†       Velocity Accuracy                           :                 0.1 meters/second without SA

†       Time Accuracy                               :                 Synchronized to GPS time – 60 ns RMS

†       Update rate                   :                 1 Hz

†       Ultra high sensitivity                       :                -175dBm or better

†       Low power consumption  :                 Max 35mA@3V Vcc

†       Serial Communication                      :                 4800 Baud (default) user selectable

†       NMEA-0183 compliant protocol or custom protocol

† Speed : Max 515m/s

† Jerk : 20 meters/sec-3 max.

† Extremely fast TTFF at low signal level

† Built in high gain LNA

† Operating voltage : 2.85V to3.3V

† Operating temperature range: -40° to 65°

† SMD type with stamp holes

† Small form factor : 25x25x3.0mm

† RoHS compliant (Lead-free)

† Accessories : 1. B type USB Cable  2. GPS Antenna

† USB : +5V

† Power Consumption : 2VA approx



PERFORMANCE SPECIFICATION

 †               Receiver Type               :                 L1 frequency band, C/A code,12-channels

†               Sensitivity                     :                 Tracking                       :                  -154dBm

Acquisition                    :                  -140dBm

†               Accuracy                       :                 Position                        :                  10m RMS without SA

Velocity                        :                  0.1m/s without SA

Timing (PPS)                :                 60ns RMS

†               Acquisition Time            :                 Cold Start                 :                 45s

(Time to first fix )                                 Warm Start              :                 38s

Hot Start                   :                  8s

Re-Acquisition         :                 <1s

† Power Consumption: Tracking           :                    35mA @3V Vcc

Acquisition                                            :                    40mA

Standby                                                  :                     5mA

† Navigation Data Update Rate: 1Hz

† Operational Limits                                :                       Altitude        : Max 18,000m

Velocity         : Max 515m/s

Acceleration : Less than 4g

EXPERIMENTS



†       Introduction to GPS

†       Establishing Link between GPS Satellite & GSP Platform

†       Measurement of Latitude & Longitude

†       Analysis of NMEA Protocols

†       Study of satellite azimuth and elevation window using sky plot

†       Study of PRN code

†       Study of Common NMEA Sentence Protocol like  GPGGA, GPGLL, GPGSA,

           GPGSV, GPRMC, GPVTG

†       Study of UTC Date & Time

†       Study of Navigation Data NMEA 1lStudy of Signal Strength View, Sky Plot View &            Position Plot

†       Development platform
