Full Wave Mid – Point Converter with ‘ R ‘ Load Trainer

SALIENT FEATURES:

• Completely self – contained stand – alone unit.
• Demonstrates the principle and working of Full Wave Mid – Point Converter with ?R? Load.
• Supply required 230V, 50Hz AC.
• Triggering circuit using UJT and Pulse transformer.
• Effect of phase control can be observed the firing circuit of Full wave mid point converter with ?R? load.
• Test points at various stages in the circuit, to observe the voltages and waveforms.
• Set of patch cords provided.
• Housed in an elegant cabinet with a well spread intelligently designed circuit layout on the front panel.
• Strongly supported by a comprehensive manual complete with theory and operating details.
